| Specification | ||||
| Code No. | D | d | Lc | L |
| 06BT2-01450 | 1 | 4 | 3 | 50 |
| 06BT2-15450 | 1.5 | 4 | 4 | 50 |
| 06BT2-02450 | 2 | 4 | 5 | 50 |
| 06BT2-25450 | 2.5 | 4 | 8 | 50 |
| 06BT2-03450 | 3 | 4 | 8 | 50 |
| 06BT2-04450 | 4 | 4 | 10 | 50 |
| 06BT2-04475 | 4 | 4 | 16 | 75 |
| 06BT2-04100 | 4 | 4 | 20 | 100 |
| 06BT2-05650 | 5 | 6 | 13 | 50 |
| 06BT2-06650 | 6 | 6 | 15 | 50 |
| 06BT2-06675 | 6 | 6 | 25 | 75 |
| 06BT2-06100 | 6 | 6 | 30 | 100 |
| 06BT2-08860 | 8 | 8 | 20 | 60 |
| 06BT2-08875 | 8 | 8 | 28 | 75 |
| 06BT2-08100 | 8 | 8 | 35 | 100 |
| 06BT2-10075 | 10 | 10 | 25 | 75 |
| 06BT2-10100 | 10 | 10 | 40 | 100 |
| 06BT2-12075 | 12 | 12 | 30 | 75 |
| 06BT2-12100 | 12 | 12 | 45 | 100 |
| 06BT2-12080 | 14 | 14 | 35 | 80 |
| 06BT2-14100 | 14 | 14 | 45 | 100 |
| 06BT2-16100 | 16 | 16 | 45 | 100 |
| 06BT2-18100 | 18 | 18 | 45 | 100 |
| 06BT2-20100 | 20 | 20 | 45 | 100 |
| 06BT2-06150 | 6 | 6 | 40 | 150 |
| 06BT2-08150 | 8 | 8 | 50 | 150 |
| 06BT2-10150 | 10 | 10 | 50 | 150 |
| 06BT2-12150 | 12 | 12 | 60 | 150 |
| 06BT2-14150 | 14 | 14 | 60 | 150 |
| 06BT2-16150 | 16 | 16 | 60 | 150 |
| 06BT2-18150 | 18 | 18 | 70 | 150 |
| 06BT2-20150 | 20 | 20 | 70 | 150 |
Application: Stainless Steel, Cast Iron, Aluminum, Copper, Graphite, Plastics, Composite Material, Titanium, Nickel, Heat-resistant Steel, Non-alloyed, Alloy Steel, Harden Steel etc. Coating: AITiN, TiAIN, TiSIN, Naco
| Specification | ||||
| Code No. | D | d | Lc | L |
| 07BT3-01450 | 1 | 4 | 3 | 50 |
| 07BT3-15450 | 1.5 | 4 | 4 | 50 |
| 07BT3-02450 | 2 | 4 | 5 | 50 |
| 07BT3-25450 | 2.5 | 4 | 8 | 50 |
| 07BT3-03450 | 3 | 4 | 8 | 50 |
| 07BT3-04450 | 4 | 4 | 10 | 50 |
| 07BT3-04475 | 4 | 4 | 16 | 75 |
| 07BT3-04100 | 4 | 4 | 20 | 100 |
| 07BT3-05650 | 5 | 6 | 13 | 50 |
| 07BT3-06650 | 6 | 6 | 15 | 50 |
| 07BT3-06675 | 6 | 6 | 25 | 75 |
| 07BT3-06100 | 6 | 6 | 30 | 100 |
| 07BT3-08860 | 8 | 8 | 20 | 60 |
| 07BT3-08875 | 8 | 8 | 28 | 75 |
| 07BT3-08100 | 8 | 8 | 35 | 100 |
| 07BT3-10075 | 10 | 10 | 25 | 75 |
| 07BT3-10100 | 10 | 10 | 40 | 100 |
| 07BT3-12075 | 12 | 12 | 30 | 75 |
| 07BT3-12100 | 12 | 12 | 45 | 100 |
| 07BT3-12080 | 14 | 14 | 35 | 80 |
| 07BT3-14100 | 14 | 14 | 45 | 100 |
| 07BT3-16100 | 16 | 16 | 45 | 100 |
| 07BT3-18100 | 18 | 18 | 45 | 100 |
| 07BT3-20100 | 20 | 20 | 45 | 100 |
| 07BT3-06150 | 6 | 6 | 40 | 150 |
| 07BT3-08150 | 8 | 8 | 50 | 150 |
| 07BT3-10150 | 10 | 10 | 50 | 150 |
| 07BT3-12150 | 12 | 12 | 60 | 150 |
| 07BT3-14150 | 14 | 14 | 60 | 150 |
| 07BT3-16150 | 16 | 16 | 60 | 150 |
| 07BT3-18150 | 18 | 18 | 70 | 150 |
| 07BT3-20150 | 20 | 20 | 70 | 150 |
| Specification | ||||
| Code No. | D | d | Lc | L |
| 08BT4-01450 | 1 | 4 | 3 | 50 |
| 08BT4-15450 | 1.5 | 4 | 4 | 50 |
| 08BT4-02450 | 2 | 4 | 5 | 50 |
| 08BT4-25450 | 2.5 | 4 | 8 | 50 |
| 08BT4-03450 | 3 | 4 | 8 | 50 |
| 08BT4-04450 | 4 | 4 | 10 | 50 |
| 08BT4-04475 | 4 | 4 | 16 | 75 |
| 08BT4-04100 | 4 | 4 | 20 | 100 |
| 08BT4-05650 | 5 | 6 | 13 | 50 |
| 08BT4-06650 | 6 | 6 | 15 | 50 |
| 08BT4-06675 | 6 | 6 | 25 | 75 |
| 08BT4-06100 | 6 | 6 | 30 | 100 |
| 08BT4--08860 | 8 | 8 | 20 | 60 |
| 08BT4-08875 | 8 | 8 | 28 | 75 |
| 08BT4-08100 | 8 | 8 | 35 | 100 |
| 08BT4-10075 | 10 | 10 | 25 | 75 |
| 08BT4-10100 | 10 | 10 | 40 | 100 |
| 08BT4-12075 | 12 | 12 | 30 | 75 |
| 08BT4-12100 | 12 | 12 | 45 | 100 |
| 08BT4-12080 | 14 | 14 | 35 | 80 |
| 08BT4-14100 | 14 | 14 | 45 | 100 |
| 08BT4-16100 | 16 | 16 | 45 | 100 |
| 08BT4-18100 | 18 | 18 | 45 | 100 |
| 08BT4-20100 | 20 | 20 | 45 | 100 |
| 08BT4-06150 | 6 | 6 | 40 | 150 |
| 08BT4-08150 | 8 | 8 | 50 | 150 |
| 08BT4-10150 | 10 | 10 | 50 | 150 |
| 08BT4-12150 | 12 | 12 | 60 | 150 |
| 08BT4-14150 | 14 | 14 | 60 | 150 |
| 08BT4-16150 | 16 | 16 | 60 | 150 |
| 08BT4-18150 | 18 | 18 | 70 | 150 |
| 08BT4-20150 | 20 | 20 | 70 | 150 |
| Specification | ||||
| Code No. | D | d | Lc | L |
| 09BT6-06650 | 6 | 6 | 15 | 50 |
| 09BT6-06675 | 6 | 6 | 25 | 75 |
| 09BT6-06400 | 6 | 6 | 36 | 100 |
| 09BT6-08860 | 8 | 8 | 20 | 60 |
| 09BT6-08875 | 8 | 8 | 32 | 75 |
| 09BT6-08100 | 8 | 8 | 40 | 100 |
| 09BT6-10075 | 10 | 10 | 25 | 75 |
| 09BT6-10100 | 10 | 10 | 40 | 100 |
| 09BT6-12075 | 12 | 12 | 30 | 75 |
| 09BT6-12100 | 12 | 12 | 40 | 100 |
| 09BT6-12150 | 12 | 12 | 55 | 150 |
| 09BT6-14100 | 14 | 14 | 40 | 100 |
| 09BT6-14150 | 14 | 14 | 65 | 150 |
| 09BT6-16100 | 16 | 16 | 40 | 100 |
| 09BT6-16150 | 16 | 16 | 65 | 150 |
| 09BT6-20100 | 20 | 20 | 45 | 100 |
| 09BT6-20150 | 20 | 20 | 70 | 150 |
