2 Flutes Flat Specification | 2 Flutes Ball Nose Specification | ||||||||||
Code No. | D | d | Lc | L1 | L | Code No. | D | d | Lc | L1 | L |
04D0002 | 0.2 | 4 | 0.4 | 1 | 50 | 04D0002B | R0.1 | 4 | 0.4 | 1 | 50 |
04D0003 | 0.3 | 4 | 0.6 | 1.5 | 50 | 04D0003B | R0.15 | 4 | 0.6 | 1.5 | 50 |
04D0004 | 0.4 | 4 | 0.8 | 2 | 50 | 04D0004B | R0.2 | 4 | 0.8 | 2 | 50 |
04D0005 | 0.5 | 4 | 1.0 | 2.5 | 50 | 04D0005B | R0.25 | 4 | 1.0 | 2.5 | 50 |
04D0006 | 0.6 | 4 | 1.2 | 3 | 50 | 04D0006B | R0.3 | 4 | 1.2 | 3 | 50 |
04D0007 | 0.7 | 4 | 1.4 | 3.5 | 50 | 04D0007B | R0.35 | 4 | 1.4 | 3.5 | 50 |
04D0008 | 0.8 | 4 | 1.6 | 4 | 50 | 04D0008B | R0.4 | 4 | 1.6 | 4 | 50 |
04D0009 | 0.9 | 4 | 1.8 | 4.5 | 50 | 04D0009B | R0.45 | 4 | 1.8 | 4.5 | 50 |
